EC fan

UFT92ABPB Series

Frame/Housing:

Aluminum die-casting

Impeller:

Plastic or steel

Bearing System:

Ball bearing

Motor:

Brushless DC motor

Protection:

Electronically-Protected

Insulation Resistance:

Above 10MΩ, DC500V

Dielectric withstand voltage:

AC 1,500V (50/60Hz) one minute

Life Expectancy:

Ball bearing: Over 50,000 hr. (at 40℃)

Safety Approval:

UL .TUV. CE .

Description of Model No.

UF	220	A	P	A	11	H1	C	2	A
1	2	3	4	5	6	7	8	9	10

Get Latest Price

	UFT92ABPB0AH1D4A
Rated Voltage	115~230V
Frequency	50/60 Hz
Input Power	4.8(115V)/5.2(230V)
Rated Current	0.06(115VAC) 0.04(230VAC)
Locked Current	0.082(115VAC) 0.038(230VAC)
Speed	3850 RPM
Maximum Air Flow	1.4 m3/min
Maximum Air Flow	50 CFM
Maximum Pressure	8.4 mmH2O
Maximum Pressure	0.33 InchH2O
Noise	43 dB
Weights	0.225Kg

SAFETY APPROVAL
