UF175AMA Series

UF175AMA Series
UF175AMA Series
Centrifugal Fan

UF175AMA Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Shaded pole or capacitor start-run
Protection: Impedance-Protected or Thermally-Protected or Electronically-Protected
Insulation Resistance: Above 100MΩ, DC500V.
Dielectric withstand voltage AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 40,000 hr. (at 40℃)
Safety Approval: CUL, CE, TUV, either UL or ETL.
Description of Model No.
UF 190 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10





Get Latest Price
UF175AMA11H1C2A UF175AMA23H1C2A
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 60/66 W 60/66 W
Rated Current 0.48/0.51 A 0.24/0.26 A
Locked Current 0.76/0.78 A 0.37/0.38 A
Speed 2550/2900 RPM 2550/2900 RPM
Maximum Air Flow 7.2/8 m3/min. 7.2/8 m3/min.
Maximum Air Flow 244/274 CFM 244/274 CFM
Maximum Pressure 23/33 mmH2O 23/33 mmH2O
Maximum Pressure 0.9/1.3 InchH2O 0.9/1.3 InchH2O
Noise 66/70 dB 66/70 dB
Weights 1.3 kg 1.3 kg
SAFETY APPROVAL
