Centrifugal Fan

UF225(85)APA Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Shaded pole or capacitor start-run
Protection: Impedance-Protected or Thermally-Protected or Electronically-Protected
Insulation Resistance: Above 100MΩ, DC500V.
Dielectric withstand voltage AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 40,000 hr. (at 40℃)
Safety Approval: CUL, CE, TUV, either UL or ETL.
Description of Model No.
UF 220 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10


Get Latest Price
UF225(85)APA11H1C2A UF225(85)APA23H1C2A
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 115/135 W 115/135 W
Rated Current 1.15/1.2 A 0.57/0.6 A
Locked Current 2.22/2.3 A 1.14/1.15 A
Speed 2700/3000 RPM 2700/3000 RPM
Maximum Air Flow 17.5/19.2 m3/min. 17.5/19.2 m3/min.
Maximum Air Flow 618/680 CFM 618/680 CFM
Maximum Pressure 46/64 mmH2O 46/64 mmH2O
Maximum Pressure 1.8/2.5 InchH2O 1.8/2.5 InchH2O
Noise 71/75 dB 71/75 dB
Weights 2.3 kg 2.3 kg
