EC fan

UFT25GBPB Series

Frame/Housing:

Aluminum die-casting

Impeller:

Plastic or steel

Bearing System:

Ball bearing

Motor:

Brushless DC motor

Protection:

Electronically-Protected

Insulation Resistance:

Above 10MΩ, DC500V

Dielectric withstand voltage:

AC 1,500V (50/60Hz) one minute

Life Expectancy:

Ball bearing: Over 50,000 hr. (at 40℃)

Safety Approval:

UL .TUV. CE .

Description of Model No.

UF	220	A	P	A	11	H1	C	2	A
1	2	3	4	5	6	7	8	9	10

Get Latest Price

	UFT25GBPB11H1D8A	UFT25GBPB23H1D8A	UFT25GBPB0AL1D8A
Rated Voltage	115V	230 V	115V~230 V
Frequency	50/60 Hz	50/60 Hz	50/60 Hz
Input Power	75W	72W	23W
Rated Current	1.05 A	0.64 A	0.37(115VAC) 0.22(230VAC)
Locked Current	0.15 A	0.15 A	0.05(115VAC) 0.10(230VAC)
Speed	2750 RPM	2750	1750 RPM
Maximum Air Flow	23.5 m3/min	23.5 m3/min	14.2 m3/min
Maximum Air Flow	830 CFM	830 CFM	510 CFM
Maximum Pressure	30.5 mmH2O	30.5 mmH2O	12.2 mmH2O
Maximum Pressure	1.20 inchH2O	1.20 inchH2O	0.5 inchH2O
Noise	70 dB	70 dB	59 dB
Weights	2.09 kg	2.09 kg	2.09 kg
