Axial Fan

UF60D Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF60D11-H UF60D23-H
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 5/4 W 5/4 W
Rated Current 0.042/0.035 A 0.04/0.032 A
Locked Current 0.042/0.04 A 0.022/0.02 A
Speed 2400/3000 RPM 2400/3000 RPM
Maximum Air Flow 0.23/0.29 m3/min. 0.23/0.29 m3/min.
Maximum Air Flow 8.1/10.24 CFM 8.1/10.24 CFM
Maximum Pressure 1.8/2.8 mmH2O 1.8/2.8 mmH2O
Maximum Pressure 0.07/0.11 InchH2O 0.07/0.11 InchH2O
Noise 27/28 dB 27/28 dB
Weights 0.14 kg 0.14 kg
SAFETY APPROVAL
