Axial Fan

UF15KMR Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF15KMR11-H UF15KMR23-H
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/50/60 Hz
Input Power 45/45 W 43/45/45 W
Rated Current 0.54/0.51 A 0.3/0.27/0.25 A
Locked Current 0.9/0.8 A 0.5/0.44/0.38 A
Speed 2750/3150 RPM 2750/2750/3150 RPM
Maximum Air Flow 6.4/7.2 m3/min. 6.4/6.4/7.2 m3/min.
Maximum Air Flow 225/255 CFM 225/225/255 CFM
Maximum Pressure 12.5/12.5 mmH2O 12.5/12.5/12.5 mmH2O
Maximum Pressure 0.5/0.5 InchH2O 0.5/0.5/0.5 InchH2O
Noise 58/61 dB 58/58/61 dB
Weights 1.1 kg 1.1 kg
SAFETY APPROVAL
