Axial Fan

UF15KCR Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF15KCR11-H UF15KCR23-H
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 26/30 W 26/31 W
Rated Current 0.24/0.25 A 0.11/0.13 A
Locked Current 0.58/0.58 A 0.28/0.28 A
Speed 2850/3400 RPM 2850/3400 RPM
Maximum Air Flow 5.8/6.8 m3/min. 5.8/6.8 m3/min.
Maximum Air Flow 205/241 CFM 205/241 CFM
Maximum Pressure 14/18.5 mmH2O 14/18.5 mmH2O
Maximum Pressure 0.55/0.73 InchH2O 0.55/0.73 InchH2O
Noise 61/66 dB 61/66 dB
Weights 1.08 kg 1.08 kg
