UFT15PBPB Series

UFT15PBPB Series
UFT15PBPB Series
EC fan

UFT15PBPB Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Brushless DC motor
Protection: Electronically-Protected
Insulation Resistance: Above 10MΩ, DC500V
Dielectric withstand voltage: AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 50,000 hr. (at 40℃)
Safety Approval: UL .TUV. CE .
Description of Model No.
UF 220 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10





Get Latest Price
UFT15PBPB0AM1D4A UFT15PBPB0AH1D4A
Rated Voltage 115 V~230V 115 V~230V
Frequency 50/60 Hz 50/60 Hz
Input Power 16 W 20.5 W
Rated Current 0.23 A / 0.14A 0.3 A / 0.17A
Locked Current 0.18 A/ 0.11A 0.14 A / 0.09A
Speed 3000 RPM 3200 RPM
Maximum Air Flow 6.2 m3/min. 6.79 m3/min.
Maximum Air Flow 220 CFM 240 CFM
Maximum Pressure 17.78 mmH2O 17.78 mmH2O
Maximum Pressure 0.70 InchH2O 0.70 InchH2O
Noise 44 dB 60 dB
Weights 0.7 kg 0.7 kg
SAFETY APPROVAL
