UFT12ABPB Series

UFT12ABPB Series
UFT12ABPB Series
EC fan

UFT12ABPB Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Brushless DC motor
Protection: Electronically-Protected
Insulation Resistance: Above 10MΩ, DC500V
Dielectric withstand voltage: AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 50,000 hr. (at 40℃)
Safety Approval: UL .TUV. CE .
Description of Model No.
UF 220 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10





Get Latest Price
UFT12ABPB0AM1D4A
Rated Voltage 115~230 V
Frequency 50/60 Hz
Input Power 4.9(115V) 5.2(230V) W
Rated Current 0.08(115V) 0.06(230V) A
Locked Current 0.09(115V) 0.06(230V) A
Speed 3200 RPM
Maximum Air Flow 3.0 m3/min.
Maximum Air Flow 106 CFM
Maximum Pressure 8.6 mmH2O
Maximum Pressure 0.34 InchH2O
Noise 43 dB
Weights 0.29 kg
SAFETY APPROVAL
