UF250BMB-E Series

UF250BMB-E Series
UF250BMB-E Series
外转式转子风扇

UF250BMB-E Series

构架材质: 铝压铸
扇叶材质: 工业塑胶或钢
轴承种类: 钢珠轴承
马达种类: 蔽极式马达或电容启动式马达
接线方式 出线式或端子式
保护方式: 阻抗保护或温度保护或电子式保护
绝缘电阻: Above 100MΩ, DC500V.
耐电压试验 AC 1,500V (50/60Hz) one minute
寿命: 钢珠轴承:40,000小时以上(40°C以下)
安规认证: CUL, CE, TUV, either UL or ETL.
型号介绍
UF 220 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10


Get Latest Price
UF250BMB11H1C2E UF250BMB23H1C2E
Rated Voltage 115V 230V
Frequency 50/60 Hz 50/60 Hz
Input Power 112/148 W 119/158 W
Rated Current 1.00/1.50 A 0.59/0.82 A
Locked Current 1.90/1.90 A 0.91/0.91 A
Speed 2550/2700 RPM 2550/2700 RPM
Maximum Air Flow 31/32 m3/min. 31/32 m3/min.
Maximum Air Flow 1090/1130 CFM 1090/1130 CFM
Maximum Pressure 20.0/16.5 mmH2O 20.0/16.5 mmH2O
Maximum Pressure 0.78/0.65 InchH2O 0.78/0.65 InchH2O
Noise 68/70 dB 68/70 dB
Weights 1.8 kg 1.8 kg
SAFETY APPROVAL
