UF6036 Series

UF6036 Series
UF6036 Series
Cross Flow Fan

UF6036 Series

Frame: Steel with black painting
Impeller: Plastic & Aluminum
Bearing System: Ball bearing or sleeve bearing
Motor: Capacitor start-run or Shaded pole
Protection: Impedance-Protected or Thermally-Protected
Insulation Resistance: Above 100MΩ,DC 500V.
Dielectric Withstand Voltage AC1, 500V (50/60Hz) one minute
Safety Approval: CE, TUV. (UF9029 has UL, CUL approval)
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF6036CBA12HL UF6036CBA23HL
Rated Voltage 120 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 35/37 W 35/37 W
Rated Current 0.33/0.33 A 0.17/0.17 A
Locked Current 0.46/0.46 A 0.22/0.22 A
Speed 2500/2800 RPM 2500/2800 RPM
Maximum Air Flow 5.5/6 m3/min. 5.5/6 m3/min.
Maximum Air Flow 195/212 CFM 195/212 CFM
Maximum Pressure 5/7.5 mmH2O 5/7.5 mmH2O
Maximum Pressure 0.2/0.3 InchH2O 0.2/0.3 InchH2O
Noise 50/53 dB 50/53 dB
Weights 2.1 kg 2.1 kg
SAFETY APPROVAL
