Axial Fan

UF12A Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF12A11-H UF12A23-H
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 14/12 W 17/15 W
Rated Current 0.20/0.16 A 0.14/0.11 A
Locked Current 0.27/0.23 A 0.17/0.15 A
Speed 2700/3100 RPM 2700/3100 RPM
Maximum Air Flow 2.6/3.0 m3/min. 2.6/3.0 m3/min.
Maximum Air Flow 92/106 CFM 92/106 CFM
Maximum Pressure 8.0/8.0 mmH2O 8.0/8.0 mmH2O
Maximum Pressure 0.32/0.32 InchH2O 0.32/0.32 InchH2O
Noise 42/46 dB 42/46 dB
Weights 0.53 kg 0.53 kg
SAFETY APPROVAL
